Providing more than just a product...
Monitor

We are dedicated to providing practical solutions backed by a customer service approach that emphasizes the “personal connection” to you, our customer. We are committed to listen to your feedback with the goal of delivering a matchless combination of product quality, ease of purchase, low total cost and effective postsale product support.
Services that we provide in support of our products include:


Fast access to a world-wide network of sales and technical personnel
Expert advice based on 50 years of experience in powder & bulk solids
Exceptional product literature and award winning tools to simplify product selection
Full-featured website and blog packed full with information and solutions
Service department capable of in-factory product repairs or field service
On-time, quick delivery
Personalized Care
Hassle-Free Transactions
2-Year Warranty

ISO 9001 registered quality system that continually pursues “best business practices

Click on below logo to see
current ISO certificate

Click on below logo to
visit PJR Web site

ISO








Perry Johnson Registrars, Inc.



Technical Support & Application Review

Please Click Here for Technical Support and Application Questions on Monitor Technologies' Continuous Level Measurement, Point Level Indication, Solids Flow Detection, Particle Emission Monitoring and Bin Aeration.






Employee Profile

Jeff Cole

Jeff C.








TrueCap Level SensorTrueCap Light
TrueCap® MK-2
Advanced RF Capacitance Level Probe
The TrueCap® Model MK-2 RF Capacitance point level probe is designed to provide a superior and stable sensitivity threshold making it suitable for a variety of powder / bulk solids and some liquid or slurry applications.

Advanced features of the Model MK-2 include:
> Automatic immunity to material build-up on the probe by its driven shield design
> Push-button calibration
> Enhanced temperature compensation
> Maximized reliability via smart sensing algorithms like “self-validating” fail-safe protection
> Visible status LED on ordinary location units
> Versatility through a variety of configuration options including: hazardous location version, split architecture design, quick-connect process connection, stub probe, cable extensions, solid extensions, Nylon® probes, Ryton® - equiv. probes, etc.

A practical application for the TrueCap would be to use this level sensor where a residual material build-up on a different sensor would cause a false material level indication.

Principle of Operation for the TrueCap RF Capacitance Level Probe:
The vessel wall and the active probe element establish an impedance reference between each other when exposed to air which has a dielectric constant of 1. When materials with a dielectric constant greater than 1 are in close proximity to the probe, the impedance of the sensing field between the sensor and the vessel wall will change. Once the amount of change exceeds a threshold that was electronically determined during the calibration process, an output relay will either be energized or de-energized depending upon the position of the fail-safe selector on the probe’s electronic circuit board. A change of as little as .5 pico-farad is all that is necessary for the probe to sense the presence of material.

Click here for more information on the TrueCap MK-2 Level Sensor or contact Monitor Technologies LLC at
Tel.: 800-766-6486 in the USA and
Tel.: 630-365-9403 worldwide.

>>Download TrueCap Product Bulletin #413
>>Click here to learn more about other Point Level Switches from Monitor Technologies
